The KBP06 Bridge Rectifier is a silicon semiconductor component designed to convert alternating current (AC) into direct current (DC) using full-wave rectification. With a maximum repetitive peak reverse voltage of 600V and an average rectified output current rating of 2A, it is suitable for a variety of power conversion applications.
Its compact molded-plastic package features four through-hole terminals for straightforward PCB installation. Clearly marked AC input terminals and positive and negative DC output terminals simplify circuit connections.
Specifications:
– Part Number: KBP06
– Component Type: Single-Phase Bridge Rectifier
– Maximum Repetitive Peak Reverse Voltage: 600V
– Average Rectified Output Current: 2A
– Maximum RMS Input Voltage: 420V
– Rectification Type: Full Wave
– Number of Pins: 4
– Mounting Type: Through Hole (THT)
– Package: KBP
– Operating Temperature: Depends on manufacturer; typically up to 150°C junction temperature
Applications:
– AC-to-DC power supplies
– Power adapters
– Battery charger circuits
– DC power conversion
– Electronic equipment and PCB power stages
