DC-DC Step-Up Boost Converter Module 1A

The DC-DC Step-Up Boost Converter Module 1A raises a lower DC input voltage to a higher, adjustable output using a compact switching regulator circuit. It is commonly used to power 9V, 12V, or other elevated-voltage loads from a lower battery voltage such as a single Li-ion cell or a 5V USB source.

Key features:

• Adjustable Output: An onboard potentiometer sets the output voltage to match the connected load.
• Wide Input Range: Accepts a broad range of DC input voltages, making it suitable for battery and USB power sources.
• High Efficiency: A high-frequency switching topology keeps conversion losses low and heat generation to a minimum.
• Compact PCB: The small footprint fits easily into battery packs and portable project enclosures.
• Continuous 1A Output: Delivers a stable output current of up to 1A for small to medium loads.
• Easy Connections: Input and output pads are large enough to solder wires to directly, no connector needed.

Adjust the onboard trimmer while monitoring the output with a multimeter to set the exact voltage your project needs before connecting a load.
